SPECIFICATIONS:

Printing Method

Direct Thermal Line Printing

Resolution

203 DPI

Print Width

Max 72 mm

Print Speed

Max 200 mm/sec

Memory

4MB Flash

Sensor

Paper End & Cover Open

Cash Drawer Control

1 Cash Drawer

USB, Ethernet

USB, Ethernet

Barcodes

JAN8 (EAN8), JAN13 (EAN13), ITFUPC-A, UPC-E, CODE 39, CODE 93, CODE 128, CODABAR, PDF 417

Character set

USA, France, Germany, UK, Denmark I, Denmark II, Italy, Sweden, Spain I, Spain II, Japan, Norway, Latin America, Korea, Japanese, Chinese, GB18030, Gb2312

Fonts

Font A (12*24), Font B (9*17), Kanji Font (24*24)

Paper Type

Continuous Paper, Marked Paper

Paper thickness

0.06 mm - 0.08 mm

Paper roll width

80±0.5mm

Paper cut

Full cut, partial cut, tear off

Input

AC 100-240 V, 50/60Hz

Output

24V, 2.5A

Print Head Life time

100km

Cutter life time

1,000,000 cuts

Operation condition

5~ 45°C, 20~90% RH (40°C)

Storage condition

~-40°C – 60°C 20%~93% RH (40°C)

Dimension

126 (W) * 160.5 (L) * 116.5 (H) mm

3 inch, 203 DPI thermal printer, 80mm paper width

Print speed of 200 mm/sec

Compact Design and small foot print

4 MB Flash Memory

USB + serial + ethernet
