SPECIFICATIONS:

Light Source

617nm LED aimer
White LED

Supported

1D: code128, EAN-13, EAN-8, UPC-E, UPC-A, ISBN, ISSN, Code 11, Interleave 2 of 5, code 39, code 93, code 32, codabar, matrix 2 of 5, Industrial 25, IATA 25, MSI plessey, GS1 databar, plessey, Febraban, Composite.
2D: QR code, micro QR, Data matrix, PDF 417, micor PDF 417, Aztec, Hanxin, Maxicode, Dotcode, chinese direct transmission.

Scan type

Image CMOS

Resolution

640*480

Scan mode

Handheld 2D Barcode Scanner

Scan speed

300 scans/sec

Scan angle

yaw 45° rotation 360° pitch 45°

Precision

≥5million

Contrast

≥10%

Depth of scan field

EAN13 35 mm-330 mm (13 million) QR 20 mm -160 mm (20 million) PDF 417 60mm-90mm 6.67mil

Error rate

1/5 million

Interface

USB HID
USB com

Communication mode

Paired dedicated receiver
2.4g communication
paired mobile bluetooth devices
Bluetooth BLE 4.0

Transmission distance

30-50 meters (open yard)

Storage mode

Offline storage mode: when th scanner exits the connection range, the data is auotmatically stored, storage capacity is 512000 characters
Inventory storage mode: scanner can enter inventory mode.

Pairing Mode

one to one: One scanning gun pairs to one receiver, One scanner paired with bluetooth mobile device.

Operating temperature

~20℃ to 50℃

Storage temperature

~40℃ to 70℃

Relative humidity

0%~95%

Dimensions

86.5*137*168mm

Weight

279 g

Cable length

1.2 m

Drop shock resistence

Multiple times 3 mtr on concrete

Material

ABS+PC

Voltage

DC5V±5%

Operating current

280mA

Battery working time

6 hours

Lithium battery

1400ma

Standby current

0 ma

Charging time

3.5 hours

Charge mode

Contact the charging

FEATURES:

300 scans/sec

40 meters line of sight – distance covered

512K characters storage

Easy charging via cradle

Designed with an ergonomic grip

Easy Charging Cradle

Comfortable & durable scan button

Drop Shock Resistance of 3 meters on concrete
