SPECIFICATIONS:

Print method

Thermal Line Printing – Direct | Thermal & Thermal Transfer

Resolution

300 DPI ( Supported 12 dots/mm)

Memory

SDFRAM : 8 MB

Flash

8 MB

Maximum Print Width

104 mm

Maximum Print Speed

6 ips

Media Sensors

Transmission (movable) | reflection (movable) sensors

CPU

32-bit RISC CPU

Paper Type

Marked paper, Black marked, Folding paper, Punched paper

Paper Width

19-120 mm

Paper Thickness

0.06-0.20 mm

Paper Roll OD

Max. 127 mm

Paper Roll ID

25/38 mm

Width

Max.110 mm

Length

Max. 300 mm

Ribbon ID

25.4 mm

Press button indicator/Light

1 button, 2 LEDs

Operating Temp

5~45°C (41~104°F)

Storage Temp

-40~60°C (-40~140°F)

Operating Humidity

20~90% non-condensing

Storage Humidity

20~93% non-condensing

Input

110-240V AC, 50/60 Hz

Output

24 DC, 2.5 A

Dimension

210 (W) * 280 (D) * 185 (H) mm

Weight

~ 2.1 Kgs

1D Barcodes

code 3 of 9, UPCE, UPCA, interleaved 2 of 5,code 128, EAN 13, EAN 8, UCC/EAN, matrix 25, HBIC(39 code with chekcout), Codabar industry code 25, Storage and transportation code, UPC2, UPC5, Code 93, Postnet 25 (China) etc

2D Barcodes

PDF 417, maxicode, QR code etc

Communications

USB 2.0 +Serial

FEATURES:

6 inch per sec print Speed

1 inch & 0.5 inch ribbon core

8 MB Flash memory & 8 MB SDRAM

USB 2.0 + Serial

Resolution of 300 DPI ( Supported 12 dots/mm)
